Military Pneumatic Anti-Shock Garment
Model: JS-AST-C  No.:68541107
The pneumatic anti-shock garment(PASG) is utilized to provide pressure

around the lower extremities and abdomen, Called also MAST suit.
It's made of thermoplastic urethane material.Modular three removable

air chambers.Pressure gauges on each compartment and inflating

pump.Includes carry case.
Mechanism of action may include:
1. Increase of blood pressure in the hypotensive patient through

peripheral venous compression and auto transfusion of blood with upward

displacement from lower extremities.
2. Control of bleeding through direct pressure.
3. Stabilization of lower extremity/pelvic fractures through the PASG

as a semi rigid splint.


Features
·Easy Access to Femoral Site
·Modular Construction
·Nylon Water Repellent Restraint Cover
·Automatic Relief Valve
·Inflation/Deflation Valves
·Replaceable Air Chambers
·Field Maintainable
·Carrying Case and Pump Included
·Applied in 60 Seconds
·Optional Pressure Monitoring Assembly Available


JOSSUN 九生 garment, Anti-shock trousers Emergency medicine A garment-

like device placed around a Pt's legs and
abdomen–2 separate chambers and inflated to provide emergency

treatment of shock until more definitive
therapy–eg, volume replacement, transfusion, or surgery can be

performed Indications Shock with BP < 80 mmHg,
or 80–90 mmHg if evidence of hypoperfusion; splinting of pelvic and

femoral fractures; tamponade of suspected
intra-abdominal hemorrhage–eg, from a ruptured or leaking abdominal

aortic aneurysm; as an adjunct to CPR in Pts with cardiac arrest.

Specification
Size(LxW):160x110cm
Outer fabric: Nylon, waterproof
Internal gas cells: TPU,Hermetic
Foot pump: Polychloroprene
Flexible pipe: TPU latex
Pressure gauge: 0-200 mmHg
Color: Military Camouflage
Weight: 2.2Kg/set
Product package/set:36x31x19cm

Action
Applies circumferential pneumatic counterpressure to abdomen,lower

extremities.
Therapeutic Effects
Controls external bleeding by direct compression
Controls internal bleeding under trousers by
reduction of blood flow
compression of vessels
Therapeutic Effects
Stabilizes fractures
Pelvis
Femurs
Therapeutic Effects
Increases resistance to blood flow in lower body
Shunts blood to
Heart
Lungs
Brain
Produces increased blood flow to critical organs
Indications
BP below 80 systolic due to hypovolemia
Extensive soft tissue trauma to or bleeding from
abdomen or lower extremities with hypovolemic
shock
Pelvic/femur fractures with hypovolemic shock
Absolute Contraindications
Pulmonary Edema
Diaphragmatic Hernia
Relative Contraindications
Bleeding above level of suit
Head trauma
Thoracic trauma
Advanced pregnancy (legs only)
Abdominal evisceration/impaled object (legs only)
Short transport times (lt30 minutes)
Removal
At hospital under supervision of physician who
understands device
IVs established
Surgical team ready
Abdomen then one leg at a time SLOWLY
Removal
Deflation should take 20 - 60 minutes
If BP drops 4-6 mmHg, discontinue deflation,
infuse fluid
If BP drops over 10mmHg, re-inflate
Unstable patient may need to go to OR with MAST
in place
Never deflate entire suit at once
